Singlemode Or Multimode 1M, 3M, 5M, Customized Yelow color MPO Fiber Optic Patch Cord

Name: Singlemode Or Multimode 1M 3M 5M Customized Yelow color MPO Fiber Optic Patch Cord
Brand: CY COM
Price: 1 USD

Quality Singlemode Or Multimode 1M, 3M, 5M, Customized Yelow color MPO Fiber Optic Patch Cord wholesale

Place of Origin : Shenzhen , China

Brand Name : CY COM

Certification : ISO9001:2015 , RoHS

MOQ : 20

Packaging Details : PE bag

Delivery Time : 3-15 days

Payment Terms : L/C,T/T,Western Union payments for offline orders.

Supply Ability : 1 million connector / month

Product Name : Fiber Optic Patch Cord

Type : Singlemode Or Multimode

Ferrule End-face : UPC,APC

Cable Diameter : φ3.0,φ2.0,φ0.9

Cable Length : 1M, 3M, 5M, Customized

Core : Simplex, Duplex

Contact Now

Good Exchangeability Durability, high fiber density MPO Fiber Optic Patch Cord

MPO fiber optic patch cords are with MPO fiber optic connectors. They are several fiberglass connections in one such patch cord, for example, 4 fiber, 8 fiber, 12 fiber, etc. Single mode and multimode; PC, APC polishing, Male and Female types are available.

Features:

High fiber density (24 fibers for Multimode)

Low insertion loss and reflection loss

Good Durability

Good Exchangeability

High temperature stability

Application:

Testing equipment
FTTX+LAN
Optical fiber CATV
Optical communication system
Telecommunication

Specification:

Parameter	Unit	MPO-MM-PC
Insertion loss(typical)	dB	≤0.3
Return loss	dB	≥35
Exchangeability	dB	≤0.3
Vibration	dB	≤0.3
Operating temperature	℃	-40~75
Storage temperature	℃	-45~85

Ordering Information:

MPO/PC-MPO/PC-MM-12cores-2M
① ② ① ② ③ ④ ⑤
①Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
②Ferrule End-face: PC, UPC, APC
③Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
④Fiber core: 4 core, 8 core, 12 core, 24 core
⑤Cable Length: 1, 2, 3 meter or customized
⑥Cable type: PVC, LSZH, OM3, OFNR, OFNP

Singlemode Or Multimode 1M, 3M, 5M, Customized Yelow color MPO Fiber Optic Patch Cord

Product Tags:

fiber patch cord

st patch cord

Singlemode Or Multimode 1M, 3M, 5M, Customized Yelow color MPO Fiber Optic Patch Cord Images
